58.5KW+138.24KWH Solar System Solutions
58.5KW+138.24KWH Solar System Solutions
● System Configuration: 58.5kW inverter + 138.24kWh battery + 46.98kW solar panels
● Daily Power Generation: ≈ 169kWh
● Recommended For: Large farms, factories, off-grid microgrid projects
● Typical Loads: Production lines, HVAC systems, multiple machines
● Suggested Daily Usage: ≤ 170kWh/day
◆ Configuration List
| Product Name | Parameter | Quantity |
| Solar Panels | 580W | *81 |
| Hybrid Inverter | 6.5KW | *9 |
| LiFePO4 Battery | 51.2V300Ah | *9 |
| PV Combiner Box | 1 In 1Out | *1 |
| PV Combiner Box | 4 In 4Out | *2 |
| Breaker | 160A | *9 |
| Battery Cable | 0.5m 3AWG（33.7mm²） | *9 |
| Battery Cable | 1m 3AWG（33.7mm²） | *8 |
| PV Cable | 1*4mm² Red and Black | *350 |
| Connector | MC4 | *18 |
*The above configuration is for reference only. Free design is available upon request.
