32.5KW+76.8KWH Solar System Solutions
32.5KW+76.8KWH Solar System Solutions
● System Configuration: 32.5kW inverter + 76.8kWh battery + 26.1kW solar panels
● Daily Power Generation: ≈ 94kWh
● Recommended For: Small hotels, hospitals, commercial centers
● Typical Loads: Air conditioners, freezers, elevators, computers
● Suggested Daily Usage: ≤ 90~95kWh/day
◆ Configuration List
| Product Name | Parameter | Quantity |
| Solar Panels | 580W | *45 |
| Hybrid Inverter | 6.5KW | *5 |
| LiFePO4 Battery | 51.2V300Ah | *5 |
| PV Combiner Box | 1 In 1Out | *1 |
| PV Combiner Box | 4 In 4Out | *1 |
| Breaker | 160A | *5 |
| Battery Cable | 0.5m 3AWG（33.7mm²） | *5 |
| Battery Cable | 1m 3AWG（33.7mm²） | *4 |
| PV Cable | 1*4mm² Red and Black | *150 |
| Connector | MC4 | *10 |
*The above configuration is for reference only. Free design is available upon request.
Main component information
-
LW6K5-48(BJ)
Regular price $199.00Regular priceUnit price per -
15.36KWh LiFePO4 Battery
Regular price $913.00Regular priceUnit price per
