280W Monocrystalline Solar Panel PV Module for Home & Commercial Rooftop
280W Monocrystalline Solar Panel PV Module for Home & Commercial Rooftop
Each step up this family adds open-circuit voltage rather than only current, so the 280 W module reaches 40.32 V — useful when you want to keep series strings short while still hitting a target array voltage.
Technical specifications
| Maximum Power (Pmax) | 280 W |
|---|---|
| Open Circuit Voltage (Voc) | 40.32 V |
| Short Circuit Current (Isc) | 8.83 A |
| Voltage at Pmax (Vmp) | 33.6 V |
| Current at Pmax (Imp) | 8.33 A |
| Module Efficiency | 20.53 % |
| Power Tolerance | 0, +4.99W |
| Maximum System Voltage | 700 V DC |
| Max Series Fuse Rating | 20 A |
| Module Type | 210M280 |
| Solar Cells | Mono crystalline 210*105mm (4*14Pcs) |
| External Dimensions | 1550*880*30mm |
| Weight | 14.09 kg |
| Front Glass | 3.2 mm tempered glass |
| Frame | Aluminum |
| Junction Box | IP67 |
| Output Cables | 100CM 4mm² Cable |
| Connector | MC4 Compatible |
| Mechanical Load | Front Side Max. 5400Pa, Rear Side Max. 2400Pa |
| Pmax Temperature Coefficient | -0.350%/°C |
| Voc Temperature Coefficient | -0.270%/°C |
| Isc Temperature Coefficient | +0.048%/°C |
| Package Dimensions | 1565*70*895mm |
| Package Weight | 30 kg |
| Pieces per Package | 2 |
Where it fits best
- 24 V systems with moderate daily loads
- Replacing older panels while keeping the same railing
- Arrays where high string voltage is a design constraint
Questions buyers ask
Why does voltage rise but current stay similar?
The family uses the same cell current with more cells in series. That is why the 240 W through 360 W modules in this width share an 8.83 A short-circuit figure.
Is this compatible with a 24 V PWM controller?
A PWM controller would clip the extra voltage and waste it. Use MPPT to capture the full 280 W.
